| Feature | SUP 22C | SUP 22M (Mini) | SUP 32C | SUP 52C |
| Application | Single-Axis Cleaning | Ultra-Portable Cleaning | Dual-Axis Cleaning | High-Power Dual-Axis |
| Max Power Rating | ≤ 3000W | ≤ 2000W | ≤ 3000W | ≤ 6000W |
| Scan Width | 0 - 300mm | 0 - 150mm | 0 - 300mm | 0 - 300mm |
| Scan Modes | Linear (1D) | Linear (1D) | 8 Smart Modes | 8 Smart Modes |
| Collimation Length | 60mm / 75mm | 50mm | 50mm / 75mm | 100mm |
| Focusing Length | 400mm / 800mm | 400mm | 400mm / 600mm | 600mm / 800mm |
| Cooling Method | Water Cooled | Water Cooled | Water Cooled | Enhanced Water Cooling |
| Net Weight | Approx. 0.8kg | Approx. 0.6kg | Approx. 1.2kg | Approx. 1.6kg |
| Connector Type | QBH | QBH | QBH / QD | QBH / QD |
| Feature | FWH20-C20A | FWH60-C30A |
| Product Type | Intelligent Single-Swing Head | High-Power Single-Swing Head |
| Rated Power | ≤ 3000W | ≤ 6000W |
| Wavelength Range | 1070 ± 20nm | 1070 ± 20nm |
| Scan Width (Range) | 0 - 300 mm | 200 - 500 mm (Adjustable) |
| Scanning Speed | ≤ 20,000 mm/s | ≤ 40,000 mm/s |
| Collimation Length | 50 mm | 70 mm |
| Focusing Length | 400 mm / 600 mm | 1500 mm |
| Auxiliary Air Pressure | 0.5 - 0.8 Mpa | 0.5 - 0.8 Mpa |
| Effective Aperture | 16 mm | 20 mm |
| Net Weight | Approx. 0.72 kg | Approx. 2.2 kg |
| Fiber Interface | QBH | QBH |
| Control Features | Mobile App + PC Monitoring | Mobile App + 10-inch TFT Screen |
